Descripción
ey SpecificationView More
Switching Capacity
16.0 Tbps
Packet Forwarding Rate
5350 Mpps
Expansion Module Slots
Two power supply module slots (1+1 redundancy)
Six fan module slots (5+1 redundancy; at least 5 fan modules are required)
Six fan module slots (5+1 redundancy; at least 5 fan modules are required)
Management Port
One management port, one console port, and one USB port, compliant with the USB2.0 standard
Dimensions (W × D × H)
442 mm x 700 mm x 44 mm (17.40 in. x 27.56 in. x 1.73 in., 1 RU)
Ports
48 × 100GE ports (DSFP) + 8 × 400GE ports(QSFP-DD)
Operating Temperature
0ºC to 40ºC (32ºF to 104ºF)
Operating Humidity
10% to 90% RH (non-condensing)
