Descripción
Key SpecificationView More
Switching Capacity
16.0 Tbps
Packet Forwarding Rate
5350 Mpps
Expansion Module Slots
Two power supply module slots (1+1 redundancy)
Six fan module slots (5+1 redundancy; at least 5 fan modules are required)
Six fan module slots (5+1 redundancy; at least 5 fan modules are required)
Management Port
One management port, one console port, and one USB port, compliant with the USB2.0 standard
Dimensions (W × D × H)
442 mm x 670.8 mm x 43.6 mm (17.40 in. x 26.41 in. x 1.72 in., 1 RU)
Ports
24 × 200GE ports (QSFP56) + 8 × 400GE ports (QSFP-DD)
Operating Temperature
0ºC to 40ºC (32ºF to 104ºF)
Operating Humidity
10% RH to 90% RH (non-condensing)
